# How #Genesis64 parses C64 BASIC (Part 2)

Or: how operators work and mathematical equations are solved

The last post was about translating your input into something that can be run in #Genesis64, this time I'll try to shed some light on the black art of using operators and math.

```10 v=53280
20 poke v+1,0
30 print 2+2*2```

We can skip line 10 and look directly at the parameter part of the POKE command:` v+1`.
Anyone can understand it and the trick (as so often) is to make the program to understand it. The term `v+1` is pushed into the tokenizer after splitting (see Part 1) and again I use a simple regex to see what it is we want to tokenize:

`/^(.*)\+(.*)\$/`

This translates to: "Take everything until you hit a '+' and group it, then take the rest and group it as well". We are using a '+' operator, and the two groups we get are fed into the Tokenizer again to see what they are, namely a variable: '`v`' (a numerical one at that) and a number '`1`'.
So the token for '`+`' looks like:

When the program is run and the token for '`+`' is executed, it simply takes its two parameters and adds their Num value and then stores it in its Num value (which is then used by the `poke` token.

## More complex expressions

`2 + 2 * 2`

Luckily these work exactly like the simple ones, we just have to keep an eye on the order. The Tokenizer will return two tokens: a "multiplication" token and an "addition" token.

(excuse the crude drawing)

#Genesis64 parses expressions in reverse order (so lower-order mathematical operations first), but executes them back in reverse again:

```// parsing
2+2*2
-> [0] "+": 2, 2*2
2*2
--> [1] "*": 2, 2

// running
[1]: "*", 2, 2 => 4
[0]: "+" 2, [1] => 6
```

This way all other operators are parsed, too: `and`, `or` (but not: `not`), `<`, `>`, etc.

The next part(s) will be about the more complex commands like `if`/`then`, `goto`/`gosub`, and `for`/`to`/`step` as they all share the "problem" that they need to jump around the token list.

You can try out your C64 BASIC skills in #Genesis64. You can get a list of all working c64 BASIC commands and functions by typing "help" and hit enter.

Happy coding,
nGFX

# How #Genesis64 parses C64 BASIC (Part 1)

First, let's get a glimpse of what the C64 BASIC (BASIC v2) consists of. There are 76 keywords the parser of a real C64 understands:

• Operators for logic, arithmetics, and strings
• Commands
• Numerical functions
• String manipulation
• String expressions
• Output methods
 Operator Commands Numeric functions String manipulation Output AND CLOSE GOSUB NEXT RUN ABS PEEK CHR\$ SPC( OR CLR GO ON SAVE ASC POS LEFT\$ TAB( NOT CONT GOTO OPEN STOP ATN RND MID\$ + CMD IF POKE STEP COS SGN RIGHT\$ - DATA INPUT PRINT SYS EXP SIN STR\$ * DEF INPUT# PRINT# THEN FN SQR / DIM LET READ TO FRE TAN ↑ END LIST REM VERIFY INT USR = FOR LOAD RESTORE WAIT LEN VAL < GET, GET# NEW RETURN LOG >

There are also 3 system variables and a constant:

 ST (STATUS) TI (TIME) TI\$ (TIME\$) π (PI)

(Bold means that #Genesis64 understands it)

During the next couple of posts, I'll try to shed some light on how G64 handles these.

## 10 POKE53280,0

When I first had the idea of doing a C64 parser in javascript it was just this: parse C64 BASIC and I started of by reading through a good deal of articles describing how parsing is done and I read Let’s Build A Simple Interpreter. Part 1. Then I tried what I've learned by writing the first version of G64 and didn't like how it worked.

I had the morinic idea to try something a bit ... different.

In G64 parsing is done in multiple steps and the result is a list of Tokens that are then used to "run" the BASIC program. First, let's have a look at the Token structure:

Doesn't look pretty, but it does the job.

So everything in G64 that deals with BASIC either is a Token or returns one. The most important part of that structure is TokenType ... which is ... the type of the token :).

Let's do a very BASIC example program:

`10 poke53280,0`

(If you wonder why I didn't go with a simple: 10 PRINT "hello world", it is because PRINT is everything but nice and simple (but that is for another post))

As I mentioned, I decided to go the lazy way and use Regular Expressions as much as possible, so here's the first one:

`/(\d+)\s*(.*)/`

This returns two matches if the line has a line number, for the line above it returns 10 and pO53280,0.
For this post, I'm going to skip a few steps (I'll explain them in detail when dealing with PRINT and strings), for now, the next step is de-abbreviation and it simply converts pO to POKE.

Now that we have POKE53280,0 we can feed that into the Tokenizer.

`/^poke\s*(.*)\$/`

All commands have this simple Regex attached and the first thing the Tokenizer does is to loop over that list of commands and try to match their Regex (there's more, but let's try to keep it simple).

This gives us a single match: 53280,0. As POKE expects 2 numerical parameters separated by a comma, we try to split that piece of code by the comma (",").
The results are 53280 and 0. Both are fed into the Tokenizer and (as they are numbers) returned as Token, type "number" and added to POKE Token's value list.

This is what the resulting Line (and the Tokens) look like in the debugger.

Easy, isn't it?

## Run

Now that we have a Token, running it is quite easy and to make things short, here's the code for running the POKE Token:

I need to rewrite this sometime, it shows that this is one of the first commands I added.

As you can see we pass the Token itself and return a Token, which is either an EOP (EndOfPart) or ERR (as in error). If the returned value is EOP we carry on with the next Token or line, if it is an ERR the program is stopped and the error is printed.
There's also some sort of explanation added to the error Token and spit out to the console, which can be used to find an error a bit quicker.

Next time I'll explain how operators work and how mathematical equations are solved.

You can try out your C64 BASIC skills in #Genesis64. You can get a list of all working c64 BASIC commands and functions by typing "help" and hit enter.

Happy coding,
nGFX

### Let's talk keyboards.

My early take on a Genesis64 on-screen keyboard

Looking at the #C64 keyboard (with the image above being an exact copy of the layout), you'll notice a slight difference to modern keyboard layouts, like the C= (Commodore) key (although we are blessed with the Windows / Apple key), missing Alt, Tab, Esc ... you name it.

Basic input is easy ...

### Getting input working is pretty easy, sort of.

The keyboard driver is a simple affair, capturing the keydown event on the `<canvas/>` element, everything is fine as long as you stick to the ASCII range (a-z, numbers).

The first tiny obstacle is that you get a Unicode character string back when reading out the `KeyboardEvent.key` property.
Obstacle, because #Genesis64 uses the same way to render text to screen the #C64 does, by reading out the screen-ram (stored at `\$0400` by default, and the color-ram from `\$D800`, but let's ignore that).

Even though we can convert the Unicode to ASCII quite easily, getting this to PETSCII is a different matter. While PETSCII codes match with a huge part of the ASCII range, the screen-codes do NOT.

The #C64 uses PETSCII when dealing with strings, but screen-code when storing things in screen-ram. I honestly have no idea why that distinction was made.
Take the letter "A" for example, which resides at \$01 as screen-code, but at \$41 in PETSCII-verse (see: http://sta.c64.org/cbm64scrtopetext.html for some insights in the screen-code / PETSCII conversion, see also: https://style64.org/petscii/).

So how does it work in #Genesis64? In the laziest and un-heroic way possible, by using Javascript's `.indexOf`.

`public TXTSCREENCODE: string = "@abcdefghijklmnopqrstuvwxyz[£]^_ !\"#\$%&'()*+,-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ";`

If the `KeyboardEvent.key` length is 1 I can safely assume that it is a letter or a number and then simply:

`let scr: number = this.m_G64Memory.TXTSCREENCODE.indexOf(key);`

For everything >= 0, `scr` is now the screen-code of the pressed letter and the value can be stored directly in screen-ram (at cursor position, of course), should `scr` be <0 we have to investigate further ...

The fun begins when trying to reach the C= key combinations. While being conveniently shown under the letter on the #C64 keyboard there seems to be no logical connection between the symbol's screen code and the letter. You cannot simply capture the Alt key (as a replacement of the C= key) and add, say 111 to it (PETSCII values, "A" is at 65 and "" is at 176).

Adding to this particular flavor of fun is the fact that there are symbols located on keys that are in a different position on modern keyboards. I made an Excel table to see how to map keys around:

Never one for the easy way, I also use a German keyboard layout with those lovely umlauts and the § sign instead of the pound symbol (£, Shift & "3"). Just from looking at the table I'm getting a headache (as everyone who has looked into the way VICE handles keyboard layouts).

Here are just a few questions I need to find an answer for by myself:

• Use symbolic or positional layout (ie: "Z"/"Y"), does it make more sense to keep the symbol (C= & key) on that key (hence symbolic C= & "Z" will still result in "", even though the key is in a different place on my keyboard)
• Keys that have a different shifted representation (Shift & "+" is "*" on my keyboard, but "" on the #C64)
• Keys not present, like "", "" or "", not to mention Runstop or Restore.
• "ä", "ö", "ü"?

Right now I'm considering to say "fuck it" and map what can be mapped and resort for everything else to an on-screen keyboard (which is a whole different story).

And on this sober note ...
... have a good one and see you later.
